Hydraulic Cylinder Small Metal Tube Carbon / Alloy Material 1 - 30mm Wall Thickness

Hydraulic Cylinder Small Metal Tube Carbon / Alloy Material 1 - 30mm Wall Thickness

  • High Light

    hydraulic cylinder pipe

    ,

    steel cylinder pipe

  • Standard
    DIN2391
  • Material
    Carbon Or Alloy
  • Shape
    Round
  • Size
    Outer Diameter: 10-350mm, Wall Thickness: 1-30mm
  • Length
    Max 12m
  • Delivery Condition
    BK, BKW, BKS, GBK, NBK
  • Place of Origin
    Haiyan, China
  • Brand Name
    Sanxin
  • Certification
    ISO9001, ISO14001, TS16949
  • Model Number
    OD:10-350mm, WT:1-30mm
  • Minimum Order Quantity
    negotiable
  • Price
    negotiable
  • Packaging Details
    sea worthy packing in bundles or boxes
  • Delivery Time
    30-45 days after payment
  • Payment Terms
    T/T
  • Supply Ability
    1000 tons per month

Hydraulic Cylinder Small Metal Tube Carbon / Alloy Material 1 - 30mm Wall Thickness

Cold Drawn Precision Hydraulic Cylinder Steel Tube DIN2391 ST35 ST45 ST52



Standard DIN2391
Material ST35, St45, ST52
Delivery Condition BK, BKW, BKS, GBK, NBK
Size Range OD: 10-350mm, WT: 1-30mm
Length Max 12m
Surface Surface is clean and smooth, without oxide scale
Application High precision purpose, auto parts, oil cylinder, etc
Certificate TS16949, ISO 9001
Delivery Time 30-45 days after payment
Packing Bundles or Wooden Boxes



Steel Grade Chemical Composition
Symbol Material Number C Si Mn P S
Max. Max. Max. Max.
ST35 1.0308 0.17 0.35 ≥0.40 0.025 0.025
ST45 1.0408 0.21 0.35 ≥0.40 0.025 0.025
ST52 1.058 0.22 0.55 ≤1.60 0.025 0.025



Steel Grade BK BKW BKS
Name No. Rm A Rm A Rm ReH A
Mpa % Mpa % Mpa Mpa %
ST35 1.0308 480 6 420 10 420 315 14
ST45 1.0408 580 5 520 8 520 375 12
ST52 1.058 640 4 580 7 580 450 10



Steel Grade GBK NBK
Name No. Rm A Rm ReH A
Mpa % Mpa Mpa %
ST35 1.0308 315 25 340--470 235 25
ST45 1.0408 390 21 440--570 255 21
ST52 1.058 450 22 490--630 355 22
