Long Seamless Boiler Tube , Heat Exchanger Steel Tube 0.5 - 50mm Thickness

Long Seamless Boiler Tube , Heat Exchanger Steel Tube 0.5 - 50mm Thickness

  • High Light

    carbon steel boiler tubes

    ,

    industrial steel pipe

  • Standard
    BS, BS 3059
  • Grade
    10#
  • Thickness
    0.5 - 50 Mm
  • Section Shape
    Round
  • Outer Diameter(Round)
    5 - 420 Mm
  • Application
    Boiler Pipe
  • Technique
    Cold Drawn
  • Surface Treatment
    Oil
  • Product Name
    BS 3059 Gr 360 Carbon Steel Heat Exchanger Tubes
  • End Protector
    Plain
  • Type
    SMLS
  • Surface
    Oil
  • Place of Origin
    Zhejiang, China (Mainland)
  • Certification
    ISO 9001 ISO14001 TS16949
  • Minimum Order Quantity
    negotiable
  • Price
    negotiable

Long Seamless Boiler Tube , Heat Exchanger Steel Tube 0.5 - 50mm Thickness


BS 3059 Gr 360 Carbon Steel Heat Exchanger Tubes for Steel Boiler and Superheater Tubes




Product Name:BS 3059 Steel boiler and superheater tubes
Carbon ,alloy and austenitic stainless steel tubes with specified elevated temperature properties
Size
Diameter 5-420mm
Wall thickness 0.5-50mm
Length Upon request
Application : for boiler and superheater
Produce method: seamless ,welded


Delivery condition: hot finished, cold finished

Standard Data
Grade
C
Si
Mn
P
S
Cr
Mo
Ni
Others
360
0.17 max
0.10-0.35
0.40-0.8
0.035
max
0.035
max
-

-

-

-

440
0.12-0.18
0.10-0.35
0.90-1.2
0.035max
0.035
ma'x
-

-

-

-

243
0.12-0.20
0.10-0.35
0.40-0.80
0.035
max
0.035
ma'x
-

0.25-0.35
-

Al0.012 max
620-460
0.10-0.15
0.10-0.35
0.40-0.70
0.030 max
0.030 max
0.70-1.1
0.45-0.65
-

Al0.02
max

622-490
0.08-0.15
0.50
max
0.40-0.70
0.030 max
0.030 max
2.00-2.50
0.90-1.2
-

Al0.02
max

629-470
0.15
max
0.25-1.0
0.30-0.60
0.030 max
0.030 max
8.0-10.0
0.90-1.1
-
Al0.02max
629-590
762
0.17-0.23
0.50
max
1.00
max
0.030 max
0.030 max
10.00-12.50
0.80-1.20
0.30-0.80
V0.25-0.35
Grade
Tensile Strength (Mpa)
Yield Strength(Mpa)
Elongation(% min)
Flatten Coefficient
360
360-500
235
24
0.1
440
440-580
245
21
0.07
243
480-630
275
22
0.07
620-460
460-610
180
22
0.07
622-490
490-640
275
20
0.07
629-470
470-620
185
20
0.07
629-590
590-740
400
18
0.07
762
720-870
470
15
0.08
Long Seamless Boiler Tube , Heat Exchanger Steel Tube 0.5 - 50mm Thickness 0


Long Seamless Boiler Tube , Heat Exchanger Steel Tube 0.5 - 50mm Thickness 1
Packing & Delivery

BS 3059 Gr 360 Carbon Steel Heat Exchanger Tubes for Steel Boiler and Superheater Tubes Packing Details  : In bundles or in wooden boxes packaging

Delivery Details : 30-60days

Long Seamless Boiler Tube , Heat Exchanger Steel Tube 0.5 - 50mm Thickness 2
Long Seamless Boiler Tube , Heat Exchanger Steel Tube 0.5 - 50mm Thickness 3

In hexagonal bundles packaging with woven

In hexagonal shaps,the tubes will be well fixed,so it can avoid the damages when delievey .


In wooden boxes.

Solid packaging ,protecting tubes from damages much better.


In poywooden packaging,It cut the packaging costs also it can protect tubes well

In bundles with end caps.well protect tubes from rust.

Carton Packing suit for the cutting length


QUALITY CONTROL

1. Incoming Raw Material Inspection
2. Raw Material Segregation to avoid steel grade mix-up
3. Heating and Hammering End for Cold Drawing
4. Cold Drawing and Cold Rolling, on line inspection
5. Heat Treatment, +A, +SRA, +LC, +N, Q+T
6. Straightening-Cutting to specified length-Finished Measuring Inspection
7. Machanical Testing in own labs with Tensile Strength, Yield Strength, Elongation, Hardness, Impact, Mictrostruture etc
8. Packing and Stocking.



100% of our steel tubes are dimensionally checked
100% of our steel tubes are visually checked to assure they have a perfect surface condition and no surface defects.
100% eddy current test and ultrosonic test to eliminate longitudinal and transversal defects.



Impact Testing

Tensile Strength Testing

Chemical Composition Testing

FAQ

Q: Are you trading company or manufacturer ?

A: A professional steel pipes materials inventor, manufacturer and solution provider

Q: How long is your delivery time?

A: Generally it is 7-14 days if the goods are in stock. or it is 30-60 days if the goods are not in stock, it is according to quantity.

Q: Do you provide samples ? is it free or extra ?

A: Yes, we could offer the sample of BS 3059 Gr 360 Carbon Steel Heat Exchanger Tubes for Steel Boiler and Superheater Tubes  for free charge but need pay the cost of freight.

Q: What is your terms of payment ?

A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
If you have another question, pls feel free to contact us
