MOQ: | negotiable |
Price: | negotiable |
GOST 8732-78. Seamless Hot-Formed Steel Pipes
Outside Diameter: 32 – 219 mm
(32; 33,7; 38; 42; 42,4; 45; 48,3; 50; 51; 54; 57; 60; 60.3*; 63,5; 68; 70; 73; 76; 82,5*; 83; 89; 95; 102; 108; 114; 121; 127; 133; 140; 146; 152; 159; 168; 178*; 180; 194; 203; 219)
Wall Thickness: 2.8 – 46 mm
(2,8; 3; 3,2*; 3,5; 4; 4,5; 5; 5,5; 6; 6,5; 7; 7,5; 8; 8,5; 9; 9,5; 10; 11; 12; 13; 14; 15; 16; 17; 18; 19; 20; 22; 24; 25; 26; 28; 30; 32; 34; 35; 36; 38; 40; 42; 45) .
Tolerances:
OD:
D 32 – 50 mm: ± 0.5 mm
D 51 – 219 mm: ± 1%
WT:
S 2,8 – 15 mm: + 12,5% – 15%
S 16 – 30 mm: ± 12,5%
S 32 – 45 mm: + 10% – 12,5%
Notes:
1. Steel grades: 10, 20, 35, 45, 10Mn2, 15Cr, 20Cr, 40Cr, 30CrMnSi, 15CrMo, 30CrM acc. to GOST 1050-88, GOST 4543-71, GOST 19281-89.
2. Dimension marked by "*", as well as intermediate dimensions are produced subject to agreement.
3. Dimensions of pipes and tolerances according to GOST 8732-78.
4. Technical requirements according to GOST 8731-74.
5. Length from 4 up to 11.7 m depending on diameter and wall thickness.
6. Groups of metrics of quality:
BВ – with rate setting of chemical composition for killed steel (grades according to GOST 1050-88, GOST 4543-71, GOST 19281-89);
V – with rate setting of mechanical properties and chemical composition;
G – with rate setting of chemical composition and control of mechanical properties for heat-treated samples. Mechanical properties are according to steel standards.
Product Name | Round Seamless Hot Formed Structural Steel Pipe 10 , 20 , 35 , 45 , 10Mn2 , 15Cr , 20Cr |
Material | Non-alloy steel |
Section Shape | Round |
Standard | GOST 8732-78,GOST 1050-88, GOST 4543-71, GOST 19281-89 |
Grade | 10, 20, 35, 45, 10Mn2, 15Cr, 20Cr, 40Cr, 30CrMnSi, 15CrMo, 30CrM |
Brade | Torich |
Packing Details : In bundles with anti rust protection, in hexagonal bundles of structural steel pipe
Delivery Details : 30-40days
A: We are factory.
A: It is according to quantity. And usually is 35-50 days after receiving 30% T/T in advance.
A:
1.You are requested to pay for sample charges and courier charges from China to your country; and the free sample is according the product like size, steel grade and quantity, please consult our sales for details
2.Sample charges will be refunded when order is placed.
A:
1.T/T: 30% deposit in advance, the balance 70% paid before shipment
2.30% down payment, the balance 70% paid against L/C at sightMOQ: | negotiable |
