42CrMo Cnc Simulation Cnc Laser Cutter Cnc Lathe Machine Connecting Bracket
The basic parts of CNC milling machines usually refer to structural parts such as bed, column, beam, worktable, base, etc., which are large in size (commonly known as large parts), and constitute the basic frame of the machine tool. Other parts are attached to the base, and some need to move along the base. Since the base piece plays a supporting and guiding role, the basic requirement for the base piece is good rigidity.
1.Quick detail:
| Name | Cnc Laser Cutter, Cnc Simulation ,Cnc Lathe Machine |
| Material | 42CrMo |
| Surface | Degreasing, polishing, deburring,etc |
| Application | Auto parts, power industry, bridge construction,bearing,etc |
| Testing equipment | Automatic height gauge;multi-joint arm; Marble platform; Roughness measurement; etc |
| Tolerance | +/-0.01mm, 100% QC inspection |
| Package | PE plastic bag, Paper fiber, carton, wooden pallet, or as required |
| Surface treatment | Nickel-plated, zinc-plated, silver-plated, gold-plated, oxidized,Sand blasting, Brushing & polishing of cnc mechanical parts. |
| Process | Knurling, thread rolling, punching, tapping, cylindrical grinding, wire cutting |
2.What is CNC simulation?
CNC simulation processing is carried out with the support of NC simulation processing software on the computer as a platform. At present, the more popular simulation software in China include Beijing Fike VNUC, Nanjing Aerospace Yhcnc, Shanghai Yulong and other CNC machining simulation software. These software generally have three-dimensional display of CNC machining process and simulation operation that simulates real machine tools. Below we take VNUC CNC simulation software as an example to analyze the operation method of CNC simulation processing.
3.Definition of CNC Lathe Machine:
CNC lathe machine and turning centers are automatic with high precision and high efficiency. Equipped with a multi-station turret or a power turret, the machine tool has a wide range of processing performance, and can process linear cylinders, oblique cylinders, arcs and various threads, grooves, worms and other complex workpieces, with linear interpolation, arc Interpolate various compensation functions, and play a good economical effect in the mass production of complex parts.
4.Picture from our production:
5.Production facility:
TORICH offers precision CNC Laser Cutter service, based on the metal material like carbon, alloy, copper, stainless, etc. We foucus on the metal & plastic rapid prototyping and CNC machining services with low volume. TORICH has had ISO 9001 certification.
What we have: 3-axis, 4-axis and 5-axis CNC machines, Radial Drilling Machine, Automatic lathe walking machine, Cnc Machine Laser etc.
6.FAQ
Q: How long is your delivery time?
A: Generally it is 7-14 days if the goods are in stock. or it is 30-60 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples of CNC Laser Cutter accessories ? is it free or extra ?
A: Yes, we could offer the sample for free charge but need pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
Q:How to get the sample of CNC ?
A:1. You are requested to pay for sample charges and courier charges from China to your country; and the free sample is according the product like size, steel grade and quantity, please consult our sales for details
2. Sample charges will be refunded when order is placed.
Our products are sold all over the world, you can rest assured.
