CNC machining has revolutionized the manufacturing industry by introducing precise and efficient methods for creating complex parts and components. In this article, we will explore the details of CNC machining parts specifically related to 304 stainless steel equal diameter tee and 304 stainless steel compression pipe fittings.
The material used for these parts is 304 stainless steel. Stainless steel is a popular choice in various industries due to its excellent corrosion resistance, high strength, and durability. 304 stainless steel, in particular, contains a mixture of chromium and nickel, which enhances its resistance to oxidation and provides it with favorable mechanical properties.
To ensure accuracy and consistency during the CNC machining process, a detailed drawing is essential. The drawing format used for these parts can vary, but common formats include AutoCAD (DWG) and Portable Document Format (PDF). The drawing should include the dimensions, tolerances, and specifications required for the CNC machining process.
The production process for CNC machining parts involves several stages, starting from the initial design to the final product. Here is an overview of the typical steps involved:
Design: Create a detailed CAD (Computer-Aided Design) model of the part, including all necessary dimensions and specifications.
Programming: Convert the CAD model into CNC machine instructions (G-code) using CAM (Computer-Aided Manufacturing) software.
Material preparation: Select high-quality 304 stainless steel stock material and ensure it is properly prepared for machining.
CNC machining: Use a CNC milling or turning machine to accurately cut and shape the stainless steel stock according to the G-code instructions.
Finishing and deburring: Smooth out any rough edges or burrs left from the machining process to achieve the desired surface finish.
Quality control: Inspect the finished parts for dimensional accuracy, surface roughness, and adherence to specifications.
Packaging and delivery: Package the parts securely and transport them to the customer or the next stage of production.
Surface roughness is an important aspect of CNC machining parts. For the 304 stainless steel equal diameter tee and compression pipe fittings, achieving a suitable surface finish is crucial. Surface roughness is usually measured using Ra (arithmetic mean roughness) or Rz (maximum peak-to-valley height) values.
To improve the surface finish, several treatments can be applied, including:
The specific treatment used depends on the application requirements and functional needs of the parts.
To ensure the quality and precision of CNC machined parts, various inspection instruments are used. Some common instruments for inspecting 304 stainless steel equal diameter tee and compression pipe fittings include:
These inspection instruments help maintain the integrity and quality of the finished products.
304 stainless steel equal diameter tee and compression pipe fittings find applications in a range of industries, including:
| Product name | CNC Machining Parts 304 Stainless Steel Equal Diameter Tee 304 Stainless Steel Compression Pipe Fittings | |
| Production Equipment | CNC, Milling Machine Processing, CNC Lathe Processing,CNC Turning, CNC Milling, Laser Cutting, Bending, Spinning, Wire Cutting, Stamping, Electric Discharge Machining (EDM), Injection Molding | |
| Material | Stainless Steel | |
| Drawing format | STEP,STP,GIS,CAD,PDF,DWG,DXF etc or samples. | |
| Production Process | Raw material incoming inspection→Drawing Confirmation→Machine Setup→Trial Production→Sample quality check and confirmation→Mass production→Final Inspection→Packing→Ready to Ship | |
| Finish | Sandblasting, Anodize color, Blackenning, Zinc/Nickl Plating, Polish, Power coating, Passivation PVD, Titanium Plating, Electrogalvanizing, electroplating chromium, electrophoresis, QPQ(Quench-Polish-Quench), Electro Polishing,Chrome Plating, Knurl, Laser etch Logo, etc. |
|
| Application | Auto Parts, Hydraulic Hoses, Oil Machinery, Geological Drilling, MotorCycle, Bycycle, Agricultural Machine Parts, Engineering Machinary, Fastners. | |
| Surface roughness | Ra 0.1~3.2 | |
| Surface Treatment | Grinding, Polish, Deburr, Painting, Galvanization, Chrome Plating, Anodization treatment etc | |
| Inspection | 100% Dimensional Check 100% Visual Check Mechanical Properties Inspection, Internal Lab test report or Third Party Inspection Report. |
|
| Inspection Instrument | Complete inspection lab with Micrometer, Optical Comparator, Caliper Vernier,CMM Depth Caliper Vernier, Universal Protractor, Clock Gauge, Internal Centigrade Gauge |
|
| Tolerance | Customer's Drawing Request | |
TORICH is an enterprise that has been producing precision steel pipes and steel pipe processing for over 20 years, with a factory area of approximately 20000 square meters
The main products produced are carbon steel and alloy steel grade seamless steel pipes, welded precision steel pipes, DOM steel pipes, seamless and welded stainless steel pipes.And our separate workshop also produce machined cast iron parts and cast steel parts, as well ad customized precision parts and difficult precision parts. Our strength is with in our ability to produce metal parts of higher quality control in an integrated process, from mapping and mould design, to casting, forging, machining, heat treatment, surface treatment, assembly and testing.
TORICH team is familiar with the quality requirements and process standards of precision parts and steel tubes of leading industrial companies at home and abroad, constantly optimizes the production and management level, and constantly looks for like-minded excellent suppliers, which enable us to reduce the production cost and have a comparative advantage over many of our competitors.
In the field of processing, TORICH has 18 sets 4-axis/3-axis CNC machines and over 30 sets of CNC lathers. The machining center is capable of machining 1100x600x800mm parts and the CNC lathes are capable of processing 550x1500mm parts. We specialize in machining stainless steel, alloy steel and other hard metals, as well as carbon steel, aluminium, and copper, with a dimensional accuracy of 0.01mm.
As of 2023, TORICH has perfectly cooperated with more than 50 countries, including Russia, India, Australia, the United Kingdom, France, the United States, Canada, Brazil, and Egypt. Quality and reputation are always our first concerns, with the aim of well serving every customer who trusts in us. TORICH looks forward to partnering with customers all over the world.
Our products are sold all over the world, you can rest assured.
